Article specifications
| Part no. | 98437 |
|---|---|
| Item description | Wellschlauch-Verschraubung HSSV elbow 90° plastic PG 29 NW 29 black |
| Thread type | PG |
| Size | PG 29 |
| Colour | black |
| Thread length (mm) | 11,5 |
| Suitable nominal diameter | 29,0 |
| Pieces per packaging unit | 25 |
| Individual quantities available | no |
| EAN / GTIN | 4060892384745 |
| Customs tariff number | 39174000 |
Manufacturer technical information
Corrugated tubes conduit gland
Temperature range
-40°C to +110°C
Protection class
IP 65
Structure
- Material: Polyamide (PA) 6
- Flammability acc. to UL 94 (V0)
Properties
- halogen-free
- cadmium-free
- resistant to: fuels, mineral oils, greases, weak bases, weak acids
Notes
- UR-tested
- Protection classification:
- IP 66 with outer seal
- Threaded connection:
- metric to EN 60423
- Each unit includes 1 safety opener.
Application
- Machine and plant construction
- Robotics
- Automation technology
- Vehicle construction and shipbuilding
- Railway technology
- Installation technology
- Control cabinet construction
- Quick-insert glands for a reliable, quick connection.
- Suitable for parallel-coiled HELUcond protection tubes.
