HELUKAT® 600A ist ein geschirmtes CAT.7e-LAN-Kabel für die feste Verlegung im Außenbereich, etwa an Gebäudewänden und auf Kabeltrassen. Der doppelte PVC-Mantel ist für die Installation im Freien ausgelegt. Geeignet für strukturierte Netzwerkverkabelung im Tertiär- und Sekundärbereich.
Technische Daten
| Hersteller | HELUKABEL |
|---|---|
| Artikelnummer | 801147 |
| EAN / GTIN | 4060892314056 |
| Kategorie | CAT.7e |
| Aufbau | S/FTP, 4×2×AWG 23/1, PVC/PVC |
| Leiter | Blankes Kupfer; Leiterdurchmesser ca. 0,58 mm |
| Aderisolation | Foam-Skin-PE |
| Schirmung | Aluminiumfolie über den Paaren, zusätzlicher Kupfergeflechtschirm |
| Außenmantel | PVC, schwarz ähnlich RAL 9005 |
| Außendurchmesser | Ca. 11,6 mm |
| Wellenwiderstand | 100 Ω ±15 Ω (1–100 MHz); 100 Ω ±20 Ω (101–1000 MHz) |
| Schleifenwiderstand | Max. 160 Ω/km |
| Betriebskapazität | Nominal 43 nF/km |
| Relative Ausbreitungsgeschwindigkeit | 79 % |
| Betriebstemperatur | −30 bis +70 °C |
| Biegeradius, mehrmalig | 95 mm |
| Gewicht / Kupferzahl | Ca. 153 kg/km / 32 kg/km |
| Brandlast | Richtwert 2,62 MJ/m |
| Verpackung | 500 m oder 1.000 m; Einzelmengen/Zuschnitt laut Hersteller bestellbar |
| Normen / Eigenschaften | ISO/IEC 11801, EN 50173, EIA/TIA 568-A; flammwidrig nach IEC 60332-1-2 |
Hinweis: Technische Angaben nach Herstellerdatenblatt. Hersteller-Basispreis und verfügbare Verkaufseinheiten sind kein bestätigter GermanSTS-Shoppreis; Preis, Bestand und Lieferzeit müssen noch freigegeben werden.
Hersteller-Datenblatt (PDF, Deutsch)
