Teltonika PR1UCP25 – Combo MIMO Mobile/GPS Roof SMA Antenna
Manufacturer order code: PR1UCP25
Technical specifications
MECHANICAL/ENVIRONMENTAL
| Mounting type | Adhesive, Screw |
|---|
| Enclosure material | ASA |
|---|
| UV resistant | ✓ |
|---|
| Cable length | 1200 mm |
|---|
| Weight (Without package) | 120 g |
|---|
| Operating temperature | -40 °C ~ +85 °C |
|---|
| Operating humidity | Up to 95 % |
|---|
| Ingress Protection Rating | IP67 (exclude cable outlet) |
|---|
| RoHS compliant | ✓ |
|---|
MOBILE ANTENNA
| Frequency range | 698 ~ 960, 1710 ~ 2690 MHz |
|---|
| Polarisation | Linear |
|---|
| Radiation pattern type | Omni-directional |
|---|
| Gain | ≤ 2.5 dBi |
|---|
| VSWR | ≤ 3.0 |
|---|
| Impedance | 50 Ω |
|---|
| Connector type and count | 2 x SMA Male |
|---|
| Cable type | 2 x RG174 |
|---|
GNSS ANTENNA
| Frequency range | 1559 ~ 1606 MHz |
|---|
| Polarisation | RHCP |
|---|
| Radiation pattern type | Directional |
|---|
| Gain | ≤ 2 dB |
|---|
| LNA Gain | 28 ± 2 dB |
|---|
| LNA noise figure | ≤ 2 dB |
|---|
| VSWR | ≤ 2 |
|---|
| Impedance | 50 Ω |
|---|
| Supply voltage | 3 ~ 5 VDC |
|---|
| Current consumption | ≤ 20 mA |
|---|
| Connector type and count | 1 x SMA Male |
|---|
| Cable type | 1 x RG174 |
|---|
Documentation and downloads
Manufacturer technical information checked on 17 October 2026. Check compatibility, connectors, electrical limits, package contents and the complete order code before selection. Price and availability are confirmed on enquiry.
